| Swing over bed |
20 mm [OP: 23 mm] |
| Max turning diameter |
20 mm (25/32 in) [OP: 23 mm] |
| Max turning length |
205 mm (8 in) |
| Bar capacity |
20 mm [OP: 23 mm] |
| Chuck |
20 mm [OP: 23 mm] |
| Spindle nose |
Integrated Collet Sleeve / Revolving G.B. |
| Spindle speed |
Main: 10,000 rpm, Sub: 10,000 rpm |
| Motor hp |
Main: 2.95 / 4.96 HP, Sub: 2.95 / 4.96 HP |
