| Swing over bed |
26 mm |
| Max turning diameter |
26 mm (1-1/64 in) |
| Max turning length |
260 mm (10-15/64 in) |
| Bar capacity |
26 mm (1-1/64 in) |
| Chuck |
26 mm |
| Spindle nose |
Integrated Collet Sleeve / Revolving G.B. |
| Spindle speed |
Main: 10,000 rpm, Sub: 10,000 rpm |
| Motor hp |
Main: 7.38 / 10.06 HP, Sub: 4.96 / 7.38 HP |
